LED Street Light Cabinet Mlt-Slh-Ds-II

Product Description

LED Street Light Cabinet MLT-SLH-DS-II
Categories

LED Street Light Cabinet Mlt-Slh-Ds-II

Brief Introduction

This LED street light cabinet fixture MLT-SLH-DS-II is the small size of SMD LED street light cabinet fixture from Moonlight LED street light D series. Modern design, precision die-casting molded and superior corrosion resistant coating finish housing with standard twist lock photocell mounting platform, make this LED Street Light Housing can be used for variety of LED roadway lighting applications.

FeatureDurable aluminum alloy die-casting LED street light shell for heavy-duty outdoor lighting applications.Casting-integral heat sink with fins increased air flow velocity providing maximum passive thermal management.Easy drainage fins system.Separate LED light engine and driver box for easy maintenance.Tool-less design for replace the LED driver without any tool.Large driver box complies with Meanwell HVG series drivers.Both cover and bottom of the driver box have the GND bosses for security.Plastic electrostatic spraying to resist corrosion, chipping and fading.Adjustable knuckle slip fitter with SUS304 stainless steel hardware secures fixture to pole arm.5mm high light transmittance tempered glass diffuser.Silicon gaskets.SUS304 stainless steel bolts and clips for fasteningStandard S6000 socket and twist lock photocell mounting platform for lighting control.Quick disconnection terminal block mounting platform for disconnect the power supply for linemen handling security.IP66 rated, protect from all dust and harsh weather.Standard Gray finish.Easy to assemble, install and linemen friendly maintain.LED Street Light Cabinet Mlt-Slh-Ds-II

Parameter

Model No.LED Street Light Cabinet MLT-SLH-DS-II
Dimension of Housing54.6cm(L)*29.5cm(W)*24.3cm(H)
Fixture MaterialDie-casting Aluminum Alloy
Surface Finish ColorGray or Customized color
Material of DiffuserHigh Transmittance Tempered glass
Effective MCPCB Mounting Size252mm(L)*222mm(W)
Recommended LED Power30W to 100W
Driver Box Dimension260mm(L)*85mm(W)*65mm(H)
Pole MountingAccommodates up to Φ65mm pipe
Adjustable Slip Fitter-15°to +15°
Standard PhotocellOptional
Quick Disconnection Terminal BlockOptional
IP RatingIP66

Packing Information

Net Weight5.00kg/PCS
Gross weight6.08kg/carton
Quantity1PCS/ carton
Carton Size63.5cm(L)*33.5cm(W)*19.5cm(H)

Application

This heavy-duty, modern design and cost-effective LED street light cabinet fixture is typically used as 30W-100W LED street lighting fixture. LED street lighting is used extensively in urban settings, along small town downtown main streets, in residential neighborhoods, in commercial districts, public squares, in industrial parks, at interstate highway interchanges, bridges, and rural intersections.

Packing
LED Street Light Cabinet Mlt-Slh-Ds-II

FAQ

Q1: How could I get a sample?
A1: Email us the models and quantity of our LED light housings you need, and tell us your express account number for shipment, then we send you the PI. When you have transferred the money, send us the TT copy for check. We will send out samples within 3 working days after we get the payment for general models of our LED lighting fixtures.

Q2: How to place an order?
A2: Email order details to sales department including items model number, quantity, destination port (we need it to calculate the shipping cost), selling countries, consignee's contact information including detail address and phone fax number and email address, notify party, etc.

Q3: Could we place order by OEM or ODM style to produce our own brand products in your factory?
A3: Of course you can. Welcome to do OEM or ODM Order for our LED lighting fixtures. What you need to do is to send us the Drawing of your style with products, and we will submit sample or prototype of LED light housings to you for your approval.

Q4: What kind of shipment will you use?
A4: EMS, TNT, DHL, FEDEX, AIR WAY, SEALAND. Because our LED lighting fixtures especially LED street light housings are very heavy, normally we will choose the most economic way for the shipment. But if you need the samples urgently, please kindly remind us.

Q5: How soon we can get the shipment?
A5: It depends on your models of LED light housings you have selected and order volume. Please tell us the models and quantity, so we can confirm with you via Email.

Q6: Can I choose a custom color?
A6: Yes. You can. But the powder supplier will request a MOQ for the coating powder of our LED light housing, and the delivery time will be a little longer for the special color LED lighting fixture.

Q7: How long warranty do you provide for your products?
A7: We provide 3-year warranty only for quality-related issues of our LED lighting fixtures. Once the quality problem is confirmed, you can request free replacement for them.

Contact us if you need more details on LED Street Light Cabinet. We are ready to answer your questions on packaging, logistics, certification or any other aspects about LED Street Light Casing、LED Street Light Shell. If these products fail to match your need, please contact us and we would like to provide relevant information.
